Optimized for heavy industrial mains and transformer connections, achieving low impedance and superior short-circuit withstand capabilities under continuous heavy loads.

1. AI & Large-Scale Data Centers

Application Logic

The explosive growth of AI computing power has led to a dramatic increase in power consumption per rack. Traditional remote power panels (RPPs) and cable trays can no longer meet the demands of high-density power supply. Busway systems ranging from 1600A to 4000A can be directly utilized for track busway power distribution (Row Power Distribution). This supports hot-swapping and enables flexible, seamless expansion.

Core Data

 Power Supply Reliability: Supports dual-busbar redundant power supply, ensuring the UPS system achieves a 99.999% availability rate.

 Space Optimization: Saves 50%–60% of wiring and installation space compared to traditional cable trays.

 Temperature Rise Control: Under full-load operation, the temperature rise is strictly controlled at \le 60\text{K}, effectively preventing accelerated insulation aging.

2. Industrial Plants & Heavy Manufacturing

Application Logic

Our busway systems serve as the primary power distribution solution for heavy-duty applications, including large electric motors, variable frequency drives (VFDs), metallurgical production lines, and automotive welding lines. These environments are characterized by high-impact loads and frequent start-stop cycles, requiring exceptional short-circuit resistance and superior thermal dissipation performance.

Core Data

 Short-Circuit Withstand Capacity: Features a rated short-time withstand current (I_{cw}) of 80\text{kA} - 100\text{kA}/1\text{s}, with a peak withstand current \ge 176\text{kA}, effectively mitigating the impact of frequent load fluctuations and electrical surges.

 Energy Efficiency: Compared to traditional cables of the same cross-section, our busway reduces impedance by 15\% - 25\%, leading to a 15\% - 20\% reduction in annual energy losses.

 Ingress Protection (IP): Engineered for harsh industrial environments, offering protection ratings from IP54 to IP65, ensuring full resistance against dust ingress and low-pressure water jets.
